The main structure of the oil pressure buffer is composed of a body, a shaft, a bearing, an inner tube, a piston, a hydraulic shaft, a spring, etc., when the shaft is impacted by an external force, the hydraulic oil of the inner tube is squeezed by the piston, and the hydraulic oil is pressed. The oil drain hole of the inner tube is discharged one by one, and the hydraulic oil discharged from the inner tube is also returned to the inner tube by the oil return hole of the inner tube; when the external force disappears, the spring bounces the piston back to the next point to wait for the next action.
◈ Material:Carbon steel
◈Color:Black
◈ Head of the buffer:Nylon
◈Number of slides:300 W
◈Working temperature:-10 ~+85 ℃
◈Stroke:30 mm
Attention To AD Series Buffer
◈ Before using, set the adjustment knob to “4” and observe the impact effect before adjusting to the most appropriate position.
◈If "bang" sound is left at the end of the stroke of "4" scale, it indicates that the damping force of the product is too small and needs to be adjusted upwards
◈If there is a loud noise at the moment of contact, the damping force is too large and should be adjusted downward.
◈Need to increase or decrease step by step when adjusting, do not jump adjustment.
