The AC series Self-compensation Shock absorber can absorb the kineticobject energy as soon as possible. It converts kinetic energy into thermal energy and outputs it to the air to avoid the mechanical damage and enhance the safety of mechanical operation, prolong the service life of the machine also. Mainly used in the fields of manipulator, pneumatic cylinder, Conveyor Systems, Factory Automation, medical instruments etc.
◈Body material: Iron
◈Stroke:10 mm
◈Working temperature:-10 ~+80 ℃
◈ Impact speed: Middle speed
Principle
When piston rod is impacted, it will
drive piston to press oil in inner tube. Oil will be pressed out through
orifice holes of inner tube. At the same time, the oil returns to inner
tube through returning hole of inner tube.
After outside force vanishes, spring makes piston rod immediately return to its position. Oil will return to inner tube through check valve. Then shock absorber will return to be ready position waiting for next action.
Attention
1. It is strictly prohibited to knock or collide the shaft, which may easily lead to bending of the shaft.
2.
The surface of the shaft should not be covered with sewage or dirty
oil, and the shaft must operate in a clean environment.Otherwise, it
will increase the probability of product leakage and reduce the service
life of the product.
3. It is strictly prohibited to spray paint on
the pipe teeth and axis, otherwise it will affect the heat dissipation
effect and oil leakage.
Feature
| Model | Stroke （mm） | Max. Impact Speed (m/s) |
| AC1410-2 | 10 | 2 |
| AC1420-2 | 20 | 2 |
| AC1425-2 | 25 | 2 |
| AC2020-2 | 20 | 2 |
| AC2030-2 | 30 | 2 |
| AC2050-2 | 50 | 2 |
| AC2525-2 | 25 | 2 |
| AC2550-2 | 50 | 2 |
| AC3660-2 | 60 | 2 |
Quality Standards :
The
company for the products are brand new original products, no
second-hand and refurbished products, or leave a compensable ten and
return the full amount , but the buyer due to our purchase of model
error is not responsible for returns, another of the company's sales of
products enjoy one year from the date of shipment quality assurance ,
according to the original quality standards , during warranty with
product problems , need confirmation testing by the manufacturer , the
supplier to be solved , the demand side due to storage , use, poor
maintenance caused by lower-quality product , and not raise objections
Samples
You
can send a sample to customize the products, we have many engineers can
help it; If you want a product of mine, but you are not sure if it's
what you want, so you can ask for a sample from me, it will be free.
After-sale service
We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.
