black air cylinder shock-absorp aluminium alloy energy compressed

Latest products

CA50T GOYEN High-Altitude Pulse Valve 2-inch Right Angle Type Suitable diaphragm K5004 K5000

GOYEN Pulse valve assembly CA62T010-300 Pulse valve diaphragm CA62T010-305 CA45T010-300

GOYEN CA45T01011/2 high-altitude pulse valve 1.5-inch right angle type suitable diaphragm K4502K4503

GOYEN 3 incch K7600/K7602/K7604 CA76T/MM/RCA76T/MM 3 "nitrile rubber nylon tray/fluororubber

Product Information
Feedback

Material: Carbon steel

Certification: CE, CQC

Availability: OEM

Delivery Time: 5 days

Supply Ability: 1000 PCS/Week

Product Comparison

Well-chosen in material, fine in workmanship, excellent in quality and favorable in price, AIRWOLF's pneumatic components is highly competitive in the domestic and foreign markets.AIRWOLF's pneumatic components has the following advantages over other similar products.

Enterprise Strength

AIRWOLF takes customer's satisfaction as an important criterion and provides thoughtful and reasonable services for customers with a professional and dedicated attitude.

Company Advantages
1. Extensive product checks are carried out on AIRWOLF double acting pneumatic cylinder . The test criteria in many cases such as flammability test and colorfastness test go far beyond applicable national and international standards.
2. The product is resistant to chemicals to some extent. Its surface has gone through special dipping treatment that helps resist acid and alkaline.
3. The product has a large customer base and a huge market development space.
4. The potential applications of this product are exciting.

Detailed Description

The main structure of the oil pressure buffer is composed of a body, a shaft, a bearing, an inner tube, a piston, a hydraulic shaft, a spring, etc., when the shaft is impacted by an external force, the hydraulic oil of the inner tube is squeezed by the piston, and the hydraulic oil is pressed. The oil drain hole of the inner tube is discharged one by one, and the hydraulic oil discharged from the inner tube is also returned to the inner tube by the oil return hole of the inner tube; when the external force disappears, the spring bounces the piston back to the next point to wait for the next action.

AIRWOLF black air cylinder aluminium alloy energy compressed-1

Technical specifications

◈ Material:Carbon steel

◈Color:Black

◈ Head of the buffer:Nylon

◈Number of slides:300 W

◈Working temperature:-10 ~+85 ℃

◈Stroke:30 mm

Features

AIRWOLF black air cylinder aluminium alloy energy compressed-2

part.1

Please aim the impact object at the center of the shaft so that the direction of movement of the object is consistent with the direction of the shaft core.

AIRWOLF black air cylinder aluminium alloy energy compressed-3

part.2

Eliminate shocks such as vibration and collision damage caused by non-mechanical motion.

AIRWOLF black air cylinder aluminium alloy energy compressed-4

part.3

Do not remove the front end cap, as unloading the cap will lengthen the piston rod and cause the piston rod to hit the bottom, which may break the bottom.

AIRWOLF black air cylinder aluminium alloy energy compressed-5

part.4

It is forbidden to paint on the teeth and the shaft, otherwise it will affect the heat dissipation and oil leakage.

Attention To AD Series Buffer

◈ Before using, set the adjustment knob to “4” and observe the impact effect before adjusting to the most appropriate position.

◈If "bang" sound is left at the end of the stroke of "4" scale, it indicates that the damping force of the product is too small and needs to be adjusted upwards

◈If there is a loud noise at the moment of contact, the damping force is too large and should be adjusted downward.

◈Need to increase or decrease step by step when adjusting, do not jump adjustment.

Company Features
1. Standing out from the domestic market, AIRWOLF CO, LTD has been recognized as an expert in the development, manufacture, and selling of double acting pneumatic cylinder .
2. AIRWOLF CO, LTD has advanced production technology and strict quality management system.
3. By strictly complying with environmental obligations, we ensure that the use of energy, raw material, and natural resources are legal and environmentally friendly. We strive to build trust with society through our efforts to operate with high values and integrity and to find new ways to expand customers' access to our products and services. We have devoted philanthropic efforts to help the environment. We initiate voluntary activities, such as clean the beach and recycle bottles and paper, aiming to reduce the negative impact on the environment.
