◈ Name: Shuttle Valve
◈ Working pressure range: 0~1MPa
◈ Color: Black
◈ Body material: Aluminium Alloy
◈ Working medium: Compressed air
Model | ST-01 | ST-02 | ST-03 | ST-04 | ST-06 | ST-08 |
Pipe size | 1/8" | 1/4" | 3/8" | 1/2" | 3/4" | 1" |
Effective area | 7.5mm² | 21mm² | 40mm² | 60mm² | 110mm² | 190mm² |
Working medium | Air | |||||
Working pressure range | 0~1Mpa | |||||
Operating temperature range | 0~60℃ |
Model | A | B | C | D | E | F | G |
ST-01 | 40 | 24 | 16 | 4.5 | 25 | 20.5 | 1/8" |
ST-02 | 50 | 35 | 22 | 5.5 | 35 | 25 | 1/4" |
ST-03 | 75 | 48 | 30 | 7 | 50 | 42 | 3/8" |
ST-04 | 75 | 48 | 30 | 7 | 50 | 42 | 1/2" |
ST-06 | 110 | 72 | 40 | 7 | 70 | 58 | 3/4" |
ST-08 | 110 | 72 | 40 | 7 | 70 | 58 | 1" |
◈All item Comes with Basic 3 Month Sellers Warranty, if item defective in 3 Month, We will offer replacement without extra Charger(including shipping fee)After we Receive the Defective item.
◈If item Defective after 3 Month, Buyers can still send it back, We will contact suppliers or Manufactory for Warranty. Buyers Might Need to pay the Shipping fee For resend the replaced item.
◈The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount, but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance, according to the original quality standards, during warranty with product problems, need confirmation testing by the manufacturer, the supplier to be solved, the demand side due to storage, use, poor maintenance caused by lower-quality product, and not raise objections.
You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.
