Material: Nitrile, Viton
Certification: CE
Availability: OEM
Delivery Time: 1-3 work days
Start Port: Ningbo/Shanghai
Supply Ability: 10000 PCS/Week
Company Advantages1. The raw materials of AIRWOLF diaphragm valve repair are extracted with the help of various technology. The advanced digging technology and the environmental control systems for managing airflow, water flow, and temperature guide the whole preliminary process.
2. diaphragm valve repair is good at all working conditions with valve repair kit and longer life span.
3. Compared with other types, diaphragm valve repair produced by AIRWOLF CO, LTD possess the advantages of valve repair kit .
4. Owing to the professional service, the customers of AIRWOLF has been our long term partners.
Diaphragm repair kit C113928 was suitabled for the pulse valve of ASCO series, SCXE353.060. The high quality diaphragms are reinforced and wear resistant to guarantee a long operating life, even under harsh conditions
◈Model: C113928
◈Differential pressure (PS): 0,35 - 8,5 bar [1 bar = 100kPa]
◈Ambient temperature range: -20 to +75 ℃ or 180℃
◈Material: Buna or Viton
◈Spanlife: 2 years or 1.5 millionFeature
part.1
The pulse diaphragm valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation.
part.2
The design with integral compression fittings will facilitate installation because there is no need for threaded piping.
Built-in silencers guarantee noise free operation and avoid foreign particles entering the valve.
part.3
The high flow, angle type bodies, springless construction, in combination with the special diaphragm assemblies give the unique operating features required for dust collector service applications.
part.4
The integral operators are provided with epoxy moulded F-class coils. Various optional waterproof and explosionproof solenoids for use in potentially explosive atmospheres (gas & dust) according to Directive ATEX 94/9/EC can be mounted on the same basic valve.
Advantages
1. Good air tightness
2. Aging resistance
3. Long service life
4. Strong oil resistance
5. High temperature resistance
| Ordering Code | Fitted Valve Code | Valve port size | Material |
| C113443 | G353A041,G353042, | 3/4", 1" | TPU / NBR |
| C113444 | SCG353A043, SCG353A044 | 3/4", 1" | TPU / NBR |
| C113825 | G353A045 | 1 1/2" | NBR /BUNA |
| C113826 | G353A046 | 1 1/2" | NBR /BUNA |
| C113827 | SCG353A047 | 1 1/2" | NBR /BUNA |
| C113685 C113686 | SCG353A050,SCG353A051,G353A048,G353A049 | 2" , 2 1/2" | NBR /BUNA |
| C113928 | SCEX353.060 | 3" | NBR /BUNA |
Company Features1. AIRWOLF is the first brand of the diaphragm valve repair series.
2. The AIRWOLF CO, LTD R&D staff are highly skilled.
3. We understand that giving back is what drives us to success. We encourage employees to donate time, energy, or money to their communities, such as cleaning up parks or volunteering at homeless shelters. Get an offer! AIRWOLF CO, LTD has great ambitions to acquire the primary marketplace of solenoid valve repair kit . AIRWOLF CO, LTD has a standard raw material inspection procedure. AIRWOLF CO, LTD's air valve repair kit is a symbol of strong production capabilities. Get an offer!
