PROPORTIONAL TIP CONTROL 1- AND 2-SECTIONS (ALUMINIUM HOUSING)
Max. pressure =12 bar
Min. pressure =5 bar
Max. temperature =+80°
Min temperature =-40°
Connections 1,21& 22 =G1/8”
Connection 3 =M5
Mounting holes = M6
| Part no. | Description | Section(s) | Max. pressure | Min. pressure | Voltage | Hose | Tipping | PTO |
| (bar) | (bar) | lamp (V) | connections | disengage | ||||
| 14750667H | TIP CONTROL-AIR-TS/LF | 1 | 12 | 5 | 24 | 6 mm | Spring | - |
| 14750665H | TIP CONTROL-AIR-TF/LF | 1 | 12 | 5 | 24 | 6 mm | Fixed | - |
| 14750646H | TIP-PTO CONTROL-AIR-TS/LF-PNL | 2 | 12 | 5 | 24 | 6 mm | Spring | Manual |
| 14750652H | TIP-PTO CONTROL-AIR-TS/LF-PAL | 2 | 12 | 5 | 24 | 6 mm | Spring | Automatic |
| 14750644H | TIP-PTO CONTROL-AIR-TF/LF-PNL | 2 | 12 | 5 | 24 | 6 mm | Fixed | Manual |
| 14750650H | TIP-PTO CONTROL-AIR-TF/LF-PAL | 2 | 12 | 5 | 24 | 6 mm | Fixed | Automatic |
Passed the ISO9001:2008 quality system authentication and ROHS authentication.
We can provide all kinds of certificates according to customers'needs.
FTA.CO,CQ,and Form E.
Our Workshop
Our Warehouse
Our Team
A: We are factory.
A: Yes,if your quantity more than 50pcs. we could add your logo on the products.
A: Generally it is 1-2 days if the goods are in stock. or it is 10-20 days if the goods are not in stock, it is according to quantity.
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
All item Comes with Basic 3 Month Sellers Warranty, if item defective in 3 Month, We will offer replacement without extra Charger(including shipping fee)After we Receive the Defective item.
Packing Details : Standard Carton,and other special packing according to customer's requirement
Delivery Details : Ready to ship,1-5 days after payment
