Hydraulic Tipping Valve With Long Button Pneumatic Toggle Switch

Product Information

Certification: CE

Availability: OEM

Detailed Description

Features

1. To be installed in moving devices like air cylinder, slide, etc.
2. Various operating styles.
3. Panel bore size Φ30(Option Φ25)

Product Features

◈ Body Material: Aluminum

◈ Port size: 1/4"(Option 1/8")

◈Sectional area: 018mm²

◈ Fluid: Compressed air

◈ Panel dimension: 30mm(Option: 25mm)

◈ Operating pressure range:0~9 kgf/cm²

◈ Max. operating pressure:10 kgf/cm²

◈ Long Compression stroke

◈Manually adjust is Available

◈ Long service life

◈Able to coordinate with the Pneumatic control valve

Function

part.1

Ambient temperature:-10~60℃

part.2

Standard operator color:Black: TB, LB;

Red: PB, PP, PPL, EB

part.3

Manually adjust is Available,Able to coordinate with the Pneumatic control valve.

part.4

lift valve to continue to lift the cylinder, the corresponding cylinder or support to further promote the limit valve stem

part.5

The lifting valve is reset to the initial state

part.6

Cylinder stop lifting.

Packaging

◈ Packaging Details:plastic bags,boxes, carton, pallet or as customer advice

◈ Payment Terms:T/T, Western Union,Paypal

◈Supply Ability:1000 pieces per 12 working days

Tipping valve kits

Packaging shipping
1. If order is not big enough, we will provide Door To Door service, we cooperate with UPS,DHL,FEDEX,TNT all year round,we gurantee that the shipping price that we offer to you is the most favorable price among so many suppliers in China.
2. By Air or By Sea through your forwarder is acceptable, if you have no forwarder in China, we also could find you cost-effective forwarder for your reference.
