Wide range of pressure ratings, sizes, and resilient materials provide long service life and low internal leakge
◈ Model: EF8320G174
◈ Type: 3/2 way
◈ Pipe Size: 1/4"
◈ Sealing Material: NBR
Highly flow valves for liquid ,corrosive, and air/inert gas service
Industrial applications include:
-Car wash -Laundry equipment -Air compressors -Industrial water control -Pumps
Specification
| Body Material | Brass |
| Pipe Size | 1/4" |
| Orifice Size | 3/32" |
| Cv Flow | 0.12 |
| Max Operating Pressure | Max Air : 60 |
| Max Water: 60 | |
| Max Light Oil : 60 | |
| Min : 0 | |
| Max. Fluid Temp °F | 150° |
| Sealing Material | NBR |
| Voltage | 24/DC |
| Valve Order Code | 20737 |
| Wattage | 11.6 |
| Rebuild Kit Order Code | 302201 |
| Replacement Coil Order Code | 238714-006-D* |
