Company Advantages1. AIRWOLF limit dump truck valve is manufactured by adopting advanced footwear production technologies including the CAD software during the design phase and the stitching machine in the production process.
2. The product has a high sweeping capacity. It is designed with the maximum areas for cleaning or absorbing the particles.
3. People can use it in hot and humid conditions without any concern. For example, many of customers who bought it have used it in the beaches.
Offers a complete range of tipping valves to be used for different cylinder volumes. In the beginning of 2002 introduced the new PT-valve. The XQF22-B can be used for flows from 80 up to 220 litre perminute. The pressure settings are from 150 to 350 bar. The Limit Dump Truck Valve has fully interchangeable pressure.
◈ Body Material: Aluminum
◈ Seal Material: HNBR
◈Working Pressure: 0.5-12 Bar
◈ Ambient temperature: -55℃-180℃
◈ Port Size: 1/8"
◈ Pressure reset and Spring resert Structure
◈ Flexible action
◈ Long Compression stroke
◈Manually adjust is Available
◈ Long service life
◈Able to coordinate with the Pneumatic control valve
part.1
Push the air control valve handle to the "lift" section
part.2
The cylinder is extended and the car body is lifted
part.3
When the cage body is lifted to the set Angle, the oil cylinder or support should contact and push the limit valve stem
part.4
lift valve to continue to lift the cylinder, the corresponding cylinder or support to further promote the limit valve stem
part.5
The lifting valve is reset to the initial state
part.6
Cylinder stop lifting.
◈ Packaging Details:plastic bags,boxes, carton, pallet or as customer advice
◈ Payment Terms:T/T, Western Union,Paypal
◈Supply Ability:1000 pieces per 12 working days
◈To simplify the proces of choosing the right adapters and mounting equipment has prepared tippingvalve kits for tank mounted and chassis mounted valves. We have options with straight or 90 connectionsfor 3/4" & 1" high pressure hoses.
◈Pneumatic limit valve is often used in the hydraulic lifting device of dump truck. Its function is to immediately reset the lifting valve stem to the initial state when the car body is set with a certain lifting Angle. The high-pressure hydraulic oil flows back to the oil tank and makes the cylinder stop lifting the car body.
Company Features1. AIRWOLF Pneumatic is a professional dump truck control valve manufacturer in China.
2. The wide variety of professional person drives our competitiveness. Their technical and business know-how enable the company to support customers in the most demanding areas successfully.
3. We sincerely hope to establish cooperative relations with customers all over the world. Inquire now! We always pursue high-quality products. Inquire now! We take our responsibility for the environment seriously. With streamlined manufacturing processes, efficient on-demand options, state-of-the-art machinery, and fulfillment services, we will bring green solutions to customers every day. Inquire now! In all of our business activities, we keep honest and respectful in communication and interactions with clients. We hope to build long-term business cooperations in such way.
