BKQF34-A is Hyva type 14750667H proportional dump truck control valves, the lever position in stainless steel metal. The tipping controls are standard delivered with three positions: tip, lower and automatic neutral locking position. We have the three types: BKQF34-A , BKQF34-B and BKQF34-C, BKQF34-C equipped with PTO function and a warning light to show that the P. T.O. is engaged, BKQF34-B equipped with PTO function but without the light. There are 4 holes : air inlet, air exhaust, lowering connection (to tipping valve), tipping connection (to tipping valve).
part no. description
Explanation of codes:
specifications
| Max. pressure | 12 bar |
| Min. pressure | 5 bar |
| Max. temperature | +80℃ |
| Min temperature | - 40℃ |
| Connections 1, 21, 22 | G1/8" |
| Connection 3 | M5 |
| Mounting holes | M6 |
Quality Standards :
The
company for the products are brand new original products, no
second-hand and refurbished products, or leave a compensable ten and
return the full amount , but the buyer due to our purchase of model
error is not responsible for returns, another of the company's sales of
products enjoy one year from the date of shipment quality assurance ,
according to the original quality standards , during warranty with
product problems , need confirmation testing by the manufacturer , the
supplier to be solved , the demand side due to storage , use, poor
maintenance caused by lower-quality product , and not raise objections
Samples
You
can send a sample to customize the products, we have many engineers can
help it; If you want a product of mine, but you are not sure if it's
what you want, so you can ask for a sample from me, it will be free.
After-sale service
We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.
