BKQF34-CQL AC-34 Proportional Valve Pneumatic Control Dump Truck Valve-AIRWOLF

Related Products

Hand Valve Tipper Air Controls DCM01 D1380001 14750430H Dump control Valves

14750152H 5 hole dump truck controls 3 way distributor Valve with Waming Light Automatic return Lever

Dump truck controls EU standard PTO raise hold lower 3 position 6 hole with light tipper control valve

Dump truck hydraulic parts system 6 hole hand valve tipper control valve

Product Information
Customer Reviews

Overview

Quick Details

Type:: Truck Shut-Off Valves, Control Dump Truck Valve

Place of Origin:: Zhejiang, China

Brand Name:: Airwolf

Model Number:: AC-34 BKQF34-CQL

Application:: General

Temperature of Media:: High Temperature

Power:: Pneumatic

Media:: Gas

Port Size:: 1/8"

Structure:: Irregular structure

Product name:: Dump Truck Valve

Connection:: BSP

Color:: slivery

Material:: Aluminium alloy

Fluid:: air

MOQ:: 1PC

Warranty:: 1 Year

Packing:: Carton

Certificate:: ISO9001

Packaging & Delivery

Selling Units:: Single item

Single package size:: 10X5X5 cm

Single gross weight:: 0.900 kg

Package Type:: Standard Carton,and other special packing according to customer's requirement

Picture Example:

Lead Time :

Quantity(Pieces)	1 - 10	11 - 100	>100
Est. Time(days)	5	10	To be negotiated

Product Description

Proportional control valve mounted in the cab for three position four way remote control valves,When dropped by controlling the rotation angle of the bar handle to achieve different pressure output, With Hydraulic lift valve used in conjunction and control the rate of decline.
1. dropped proportional control:By controlling the joystick,adjust the output pressure until it reaches a corresponding increase in the input system pressure.
2.PTO control switch: By knob Switching gas path of two position three way valve to control PTO.

Size	1/8"
temperature	medium temperature
Material	aluminum alloy
Fluid	Air
Type	Dump truck valve
