NORGREN Type Air pneumatic pulse valve 8296600.8171 1-1/2“ Aluminium Alloy

Product Information
Customer Reviews

Material: Aluminium Alloy

Certification: CE, CQC

Availability: OEM

Delivery Time: within 1-10 working days after payment

Start Port: Ningbo / Shanghai

Supply Ability: 5000 Pieces / Week

Application Scope

AIRWOLF's pneumatic components is widely applicable in the Manufacturing General Mechanical Components Design Services industry.AIRWOLF is committed to providing customers with high-quality pneumatic components as well as one-stop, comprehensive and efficient solutions.

Enterprise Strength

AIRWOLF owns an R&D team and a management team which consists of experienced experts, technicians, and management staff. We have the ability to come up with specific solutions based on the occurred problems during the production.
On one hand, AIRWOLF runs a high-quality logistics management system to achieve efficient transportation of products. On the other hand, we run a comprehensive pre-sales, sales and after-sales service system to solve various problems in time for customers.
AIRWOLF upholds the value of 'high-quality service, high-tech innovation, high-speed development'. We seek excellence based on laborious efforts and dedication. We constantly pursue progress and development, so as to provide professional and distinctive services.

Company Advantages
1. AIRWOLF hydraulic components is completed by following the highest production standards.
2. With a process of quality control, the quality is guaranteed to be high quality.
3. pneumatic components based on hydraulic components materials has the characteristic of hydraulic components.
4. Our pneumatic components is fully in line with the market's judgment whatever in quality or in shape.
5. Developing superior pneumatic components in AIRWOLF CO, LTD better guarantees the quality of customer satisfication.

Detailed Description

Dust filter systems have gained in importance over the years as environmental standards have risen. Air or gas contaminated with dust must nowadays be filtered before it can be discharged into the atmosphere. Pulse jet valve is the most important part of dust filter systems. It is widely used in Lime Industry, Chemical Working Indusrty, Environment, Mining, Pharmaceutical Indusrty etc.

Ordering Code: 8296600.8171

Material

◈Body: Aluminum

◈ Seat Seal: TPE

◈Spring: 304 SS

◈ Screws: 302 or 304 SS

Specifications

◈ Port size: 1 1/2"

◈ Switching function: normally closed

◈ Operating pressure: 0.4 to 8 bar

◈ Fluid temperature: -40 °C up to max. +85 °C

◈ Ambient temperature: -20 °C up to max. +85 °C

Advantages

part.1

The pulse diaphragm valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation.

part.2

The high flow, angle type bodies in combination with the special main diaphragm assemblies give the unique operating features required for dust collector service applications.

Maintenance

◈ Before conducting any maintenance activity on the system ensure that components are fully isolated from pressure and power supplies. Pressure and power should not be reapplied until the valve has been fully assembled.

◈ Diaphragm and pilot inspection should be conducted annually.

Packaging & Delivery

◈Packaging Details: Standard Carton box,and other special packing according to customer's requirement.

◈Port: Ningbo/Shanghai

Solenoid 8171 standard voltage: DC24V, AC24V, AC110V, AC220V

Seat seal repair Kit

Part number	For valves with solenoid 8171 and seal TPE
1261253	8296300
1261253	8296400
1261402	8296600
1268274	8296700
1268274	8296800
1271526	8392900

Drawing

Connection size G	H	H1	L	L1
G 3/4	105.5	83	95	50
G 1	105.5	83	95	50
G 1 1/2	166	136	135	70
G 2	190.5	149	170	95
G 2 1/2	205.5	160	170	95

Index	Description
101	Valve body
102	Valve cover
103	Diaphragm
104	Allen head screw
105	Diaphragm
106	Valve cover
107	Silencer
108	Silencer housing
109	Allen head screw
400	Solenoid
702	Plunger
705	Pressure spring
706	Pressure spring
707	Silencer
1400	Electrical connector (included)

Service kits

Part number	For valves with solenoid 8171 and seal TPE
1261253	8296300
1261253	8296400
1261402	8296600
1268274	8296700
1268274	8296800

Delivery
1. If the products we have in store, we will send it out ASAP after payment.
2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.
3. Also we can send by your delivery acount if you want.
4. We have a variety of ways to send goods, usually DHL, Fedex, TNL will be normal ways. If you require use of a courier, we can do it.

Competitive Advantage

Our product features	Our Services Guarantee:
1) Competitive price	1) Prompt respond (Reply with 24 hours)
2) Good quality	2) Free Samples (Customer pay for the delivery cost)
3) Professional Packaging	3) Registration support.
4) Produce according to Customers’ instruction	4) Photos/videos are available during production.
5) None delay shipment	5) Loading inspection, and send loading photos before shipment.

Warranty
All item Comes with Basic 3 Month Sellers Warranty, if item defective in 3 Month, We will offer replacement without extra Charger(including shipping fee)After we Receive the Defective item.
If item Defective after 3 Month, Buyers can still send it back, We will contact suppliers or Manufactory for Warranty. Buyers Might Need to pay the Shipping fee For resend the replaced item.

After-sale Service
We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.

Company Features
1. AIRWOLF will be an international pneumatic components supplier.
2. AIRWOLF CO, LTD strictly adopts high technology to ensure the quality of pneumatic components.
3. AIRWOLF is always looking for partners who are also seeking for a long-term trustworthy cooperation partners. Inquire! We are always here waiting for your feedback after buying our pneumatic components. Inquire! With hydraulic components supported and hydraulic components centered, AIRWOLF aims to advance towards leading brand in this field. Inquire!
