A coupling system is always as good as its sealing components. That is why we only use top quality, proven standards, which have been tried and tested time and again. For special applications, please also ask our specialist advisers, as an important criterium for functionality of an O-ring is the type of medium in relation to its temperature.quick connect couplings selection must be made so that the published rated pressure of the coupling is equal to or greater than the maximum system pressure. Pressure surges in the system higher than the rated pressure of the coupling will shorten the quick connect coupling’s life,quick connect couplings selection must assure compatibility of the body and seal materials with the fluid media used.Temperature: be certain that fluid and ambient temperatures, both steady and transient, do not exceed the limitations of the quick connect couplings. Use caution and hand protection when connecting or disconnecting quick connect couplings that are heated or cooled by the media,they are conducting or by their environment

Sealing-Material Features

part.1

NBR（Acrylonitrile-Butadiene Rubber）：Can be used for compressed air. Resistant to heat and many liquids, e.g. mineral oils, fuel (no environmental diesel), water glycol and grease.

part.2

EPDM（Ethylene Propylene Diene Rubber）：Heat resistant and specially suited to hot water and steam. Good resistance to brake oils, glycol and fire-resistant oils.Not suitable for mineral-based oils and petrol.

part.3

FKM（Fluorocarbon Rubber）：Very high resistance to heat and liquids inc. petrol, oils, environmental diesel, grease and aromatic oils.

part.4

FFKM（Perfluoro Rubber）：Universal chemical resistance, good for aggressive media, high thermal resistance. Lowest source values for all media.

Attention

◈ Couplings or parts thrown off at high speed

◈ High velocity fluid discharge

◈Contact with suddenly moving or falling objects that are to be held in position or moved by the conveyed fluid

◈Dangerously whipping hose

◈TExplosion or burning of the conveyed fluid

◈Contact with conveyed fluids that may be hot, cold, toxic, or otherwise injurious

◈Sparking or explosion while paint or flammable liquid spraying.

Structure

Hose Connection

◈ TF = Hose Barb

◈ TH = Hose Barb 45°

◈TR = Hose Barb 90°

◈ TZ = Straight shaft parallel

◈ TP = for Parker plug-in Hose

◈TS = Panel Mount with Hose Barb

◈ TD = Hose Barb DIN EN 560

◈ TE = Front Panel Installation, Hose Barb Panel Mount

Male Thread

◈ AW = Whitworth pipe thread ISO 228 parallel

◈ AM = Metric thread DIN 13

◈ AK = Whitworth pipe thread DIN 2999 tapered

◈AN = NPT thread ANSI B 1.20.1 tapered

◈ AD = Metric thread DIN 2353 (ISO 8434-1)

◈ WP = Whitworth pipe thread ISO 228 Serto Plan

◈ MP = Metric thread DIN 13 Serto Plan

◈ SW = Panel mount Whitworth pipe thread

ISO 228 Serto Plan

◈SM = Panel mount metric thread DIN 13 Serto Plan

◈ AL = Whitworth pipe thread ISO 228 parallel left

◈ AR = 90° Whitworth pipe thread DIN 2999 tapered

◈ AE = Front Panel Installation with Whitworth pipe thread ISO 228 parallel

◈ AJ = UNF thread (JIC) with 37° cone by SAE J 514
